Industrial Automation Products

ENCODER PRODUCTS • RKD3434067

702-20-S-0256-K-HV-1-G-1-SX-N-N
MODEL 702 SERIES
INCREMENTAL SHAFT ENCODER
FLAGE AND SERVO MOUNTING
UP TO 30
000 CPR
PPR - 256
SHAFT SIZE - .375"

SIZE 20 (2.0"
)
LINE DRIVER
100 KHZ (STANDARD)
CONNECTOR LOCATION - END
6 PIN

ENCODER PRODUCTS • RKD3434055

260N-T-11-S-0060-R-OC-1-S/12-FA-2-N
DISCONTINUED BY MANUFACTURER
ENCODER
MODEL 260
NO COMMUNICATION
FRONT CLAMP THRU-BORE
5/8 INCH BORE SIZE
60 PPR

ENCODER PRODUCTS • RKD3434061

611469-010
ENCODER
5-28VDC

ENCODER PRODUCTS • RKD3434058

58TF-11SG-X1024B4HV-S-MX-T6S3
ENCODER
THRU-BORE
5/8"
BORE
3.50"
TO 5.90"
B.C. (4.5"
C-FACE) TETHER ARM KIT
LINE DRIVER
10-PIN MS

ENCODER PRODUCTS • RKD3434064

702-20-S-0192-Q-PU-1-F-2-SW-N-N
INCREMENTAL SHAFT ENCODER
3/8"
SHAFT
1092HZ
1.181"
FEMALE PILOT MOUNT
IP64

ENCODER PRODUCTS • RKD3434052

260-N-T-10-S-0360-Q-OC-1-S-SF-1-N
DISCONTINUED BY MANUFACTURER
INCREMENTAL ENCODER
1/2 IN BORE SIZE
0-70 C OPERATING TEMPERATURE
360 CYCLES PER REVOLUTION
OPEN COLLECTOR
18 IN CABLE
IP50 FOR THRU-BORE

ENCODER PRODUCTS • RKD3434040

225A-10-600-OC-N-N-S
INCREMENTAL ENCODER
MODEL 225A
SINGLE CHANNEL
BORE SIZE 12 INCH
600 CYCLES PER REVOLUTION
OPEN COLLECTOR (5-28V IN/OUT)
NO ADDITIONAL MOUNTING
NO SEAL ( STANDARD)
6 FT CABLE

ENCODER PRODUCTS • RKD3434037

220C-12-0300-OC-.625-S
INCREMENTAL SHAFT ENCODER 12VDC 300 CPR .625 BORE

ENCODER PRODUCTS • RKD3434049

25H-11SG-1024NV1DHV-F00-S3
ENCODER
HOLLOW BORE
5/8 INCH BORE
MOUNTING: 3.50"
-5.90"
B.C.
1024 CYCLES PER REVOLUTION
5-28 VDC INPUT VOLTAGE

ENCODER PRODUCTS • RKD3434025

15T-14SD-2000B5DHV-F00-T2
INCREMENTAL ENCODER
MODEL 15T
THRU-BORE
BORE SIZE 8MM
1.575"
(40 MM) SLOTTED FLEX MOUNT
2000 CYCLES REVOLUTION
6 POLE
INPUT VOLTAGE 5 VDC
QUADRATURE (A &
B) WITH INDEX
LINE DRIVER
CONNECTOR TYPE 18 INCH CABLE

ENCODER PRODUCTS • RKD3434034

220C-10-600-OC
ENCODER 12VDC 600CPR 1/2IN BORE 6FT CABLE

ENCODER PRODUCTS • RKD3434043

225A-34-0360-OC-N-N-T
ENCODER
SINGLE CHANNEL
3/4"
/ 0.750"
BORE
360 CYCLES PER REVOLUTION
OPEN COLLECTOR OUTPUT
TERMINAL BLOCK CONNECTION

ENCODER PRODUCTS • RKD3434028

15T-15SB-1000N5RHV-F00
INCREMENTAL ENCODER
MODEL 15T
THRU-BORE
BORE SIZE 3/16 INCH
1.142"
(29 MM) SLOTTED FLEX MOUNT
1000 CYLCES PER REVOLUTION
NO COMMUTATION
INPUT VOLTAGE 5 VDC
QUADRATURE A AND B WITH INDEX
LINE DRIVER
CONNECTOR TYPE 18 INCH CABLE

ENCODER PRODUCTS • RKD3434019

15T-06SF-1000N5RHV
INCREMENTAL ENCODER
MODEL 15T
THRU-BORE
BORE SIZE 5MM
1.812"
(46 MM) SLOTTED FLEX-MOUNT
1000 CYLCES PER REVOLUTION
NO COMMUTATION
INPUT VOLTAGE 5 VDC
QUADRATURE A AND B WITH INDEX
LINE DRIVER

ENCODER PRODUCTS • RKD3434008

15T-02SC-1000A5R3LO-F00-T3
INCREMENTAL ENCODER
MODEL 15T
THRU-BORE
BORE SIZE 3/8 INCH
1.2795"
(32.5 MM) SLOTTED FLEX MOUNT
1000 CYLCES PER REVOLUTION
4 POLE
INPUT VOLTAGE 5 VDC
QUADRATURE (A &
B) WITH INDEX
LINE DRIVER ABZ
OPEN COLLECTOR UVW
CONNECTOR TYPE 18 INCH CABLE

ENCODER PRODUCTS • RKD3434022

15T-14SC-4096C5RHV
INCREMENTAL ENCODER
MODEL 15T
THRU-BORE
BORE SIZE 8MM
1.2795"
(32.5 MM) SLOTTED FLEX MOUNT
4096 CYCLES PER REVOLUTION
8 POLE
INPUT VOLTAGE 5 VDC
QUADRATURE A AND B WITH INDEX
LINE DRIVER

ENCODER PRODUCTS • RKD3434011

15T-05SF-10000NV1RHV-K00
ENCODER
INCREMENTAL
MODEL 15T
1/4 INCH / 0.250 INCH BORE SIZE
1.812 INCH (46 MM) SLOTTED FLEX-MOUNT
1000 CPR
NO COMMUNICATION
5 TO 28 VDC
QUADRATURE A &
B WITH INDEX
LINE DRIVER
18"
CABLE8 (STD) CONNECTOR TYPE

ENCODER PRODUCTS • RKD3434016

15T-05SF-1024NV1RHV-F20-CE
ENCODER
BORE SIZE: 10 MM
MOUNTING: SLOTTED FLEX
CPR: 1024
INPUT: V1 5-28 VDC
CHANNELS: GATED TO A
OUTPUT TYPE: LINE-DRIVER
CONNECTOR: CABLE GLAND
CABLE LENGTH: 20 FT 0 IN
FREQ RESP: 200 KHZ (STD)
TEMP: -20->
85C (STD)
SEALING: IP50 (STD)

ENCODER PRODUCTS • RKD3434005

15T-02SA-1000N5RHV-F00-T2
ENCODER
THRU BORE
.375 IN
9.5 MM BORE
46 MM TWO HOLE FLEX MOUNT
1000 PULSES
NO COMMUNICATION
5 VDC
LINE DRIVER
18"
CABLE CONNECTOR

ENCODER PRODUCTS • RKD3434002

15T-01SD-2000C05RHV-F00
ENCODER
THRU-BORE
.25"
BORE
40MM SLOTTED FLEX MOUNT
2000 CYCLES PER REVOLUTION
8 POLE
5VDC
QUADRATURE A&
B WITH INDEX
LINE DRIVER
18"
CABLE

ENCODER PRODUCTS • RKD3433996

15T-01SD-1000A5RHVA00-T2
INCREMENTAL ENCODER
MODEL 15T
THRU-BORE
BORE SIZE 1/4 INCH
SLOTTED FLEX MOUNT 1.575 INCH (40MM)
1000 CYCLES/REV
4 POLE COMMUTATION
INPUT VOLTAGE 5 VDC
QUADRATURE A &
B W/ INDEX
LINE DRIVER
15-PIN HEADER W/ 18"
CABLE
OPER TEMP -20

ENCODER PRODUCTS • RKD3433968

032.29530
DISCONTINUED BY MANUFACTURER
ENCODER
5-25 VDC
30 PPR
WITH CABLE

ENCODER PRODUCTS • RKD3433993

15T-01SA-5000A05RHV-F00
INCREMENTAL ENCODER
MODEL 15T
THRU-BORE
BORE SIZE 1/4 INCH
1.812"
(46 MM) TWO HOLE FLEX MOUNT
5000 CYCLES PER REVOLUTION
4 POLE
INPUT VOLTAGE 5 VDC
QUADRATURE A AND B WITH INDEX
LINE DRIVER
CONNECTOR TYPE 18 INCH CABLE

ENCODER PRODUCTS • RKD3433984

121-C4-A-5-10-S-1000-R-HV-1-S-N
INCREMENTAL ENCODER
MODEL 121
THRU-BORE
AUTO ALIGNING
4 POLE
MOUNTING STYLE A
INPUT VOLTAGE 5 VDC
BORE SIZE 12 INCH
0°
TO 70°
C STANDARD OPERATING TEMPERATURE
1000 CYCLE PER REVOLUTION
QUADRATURE (A &
B) WITH INDEX
LINE DRIVER
FREQUENCY RESPON
